• BK high speed digital cutting system

    BK cutting systems supply the best solution to make sampling and short-run production ...

    Industries: ​Automotive, Composites, Sign & Packaging, Textile, Gasket, etc.

ModelBK1311BK1713BK2011BK2516
Cutting Area (L x W)1300mm x 1100mm1700mm x 1300mm2000mm x 1100mm2500mm x 1600mm
Machine Dimensions2100mm x 1900mm2500mm x 2100mm2800mm x 1900mm3200mm x 2400mm
Customized Length5000mm
Customized Width5000mm
Max Speed1000mm/s
Precision0.1mm
Thickness50mm
File FormatDXF, HPGL, ISO
InterfaceSerial Ports
MediaVacuum
Power220V/50HZ, 380V/50HZ
Operation EnvironmentTemperature: 0℃-40℃ Humidity: 20%-80%RH
